Understanding new capacity and energy ratings

From 15^th August 2021, the way refrigerators & freezers are tested to calculate energy consumption and capacity has changed to comply with new MEPS standards.

This means that the capacity and energy ratings have changed too.

Changes to Refrigerator & Freezer Energy Efficiency Regulation

Household Refrigerator & Freezer Energy Rating Label Changes

What is MEPS? MEPS stands for minimum energy performance standards. The new testing methodology adopts the International Electrotechnical Commission (IEC) 62552-3:2015 test standard for household refrigerators and freezers, and introduces new MEPS for household refrigerators and freezers.

This change is detailed in the Energy Modelling Methodology for MEPS 2021 Compliance - July 2020 document.

What has changed in regard to energy consumption testing?

Every refrigerator is subject to a series of tests to ascertain its energy consumption in a home environment. Previously, these tests were conducted at a maximum temperature range of 32 degrees Celsius. Now, two tests will be conducted, one at 16 degrees Celsius and the other at 32 degrees Celsius, which simulates the more typical home environment.

What does this mean to you?

This simulation will now provide a more average result and therefore energy consumption ratings (Measured in kwhr/year) may be lower than the current published figures and may have an overall impact in the energy star rating too.

What has changed in regard to capacity calculations?

A significant change will be how volumes are measured. Under the new testing requirements, when compartment volumes in refrigerators and freezers are measured, only spaces that consumers can access for storage will count towards an appliance’s total volume. These volumes are sometimes the same, but in most cases will be slightly smaller than volumes measured using the old Australian/New Zealand methodology, which sometimes included space that consumers could not access. The result is that consumers will be able to better compare the size of appliances based on their declared volumes.

For example, a manufacturer could previously claim a refrigerator as a 400 litre appliance, but under the new regime, suppliers may only be allowed to claim that the same refrigerator has 390 litres of capacity. However, the differences in claimed volumes will be dependent on the appliance’s characteristics. For example, the volume of a chest freezer that is not frost free will not change because all of the space inside the freezer compartment is accessible to the user. However, the volume of an upright freezer that has cold air ducting space that cannot be accessed to store food will not be included in the volume that consumers see on the energy rating label.

How can tell which fridge is measured in the new ratings & capacities?
From 15 August 2021 all refrigerators manufactured or imported must comply with the new Minimum Energy Performance Standards (MEPS), however products manufactured or imported before this date that do not meet new MEPS can be sold by suppliers indefinitely.

This means that you may have 2 products with the same model number in-store side by side with varying capacities and energy ratings. The products will be essentially the same, one will have been manufactured before 15 August 2021, and the other post that date. The model SKU will remain unchanged.

Westinghouse will use POS to highlight the changes to both capacity and energy ratings.

barcode

Attached is a full list of before and after capacities and energy ratings for products that have been affected by this change.

Brand	Model name on Energy label (Final)	Volume (Litres) new Std.	Energy Star (New Std.)	New Energy on label (kwh/y)	Volume (Litres) old Std.	Energy Star (old Std.)	Old Energy on label (kwh/y)
Westinghouse	WBB3400AH	317	3.5	310	339	3.5	331
Westinghouse	WBB3400WH	317	3.5	310	339	3.5	331
Westinghouse	WBB3700AH	346	3.5	315	369	3.5	344
Westinghouse	WBB3700WH	346	3.5	315	369	3.5	344
Westinghouse	WBE4500BC	425	4.5	292	453	4.5	299
Westinghouse	WBE4500SC	425	4.5	292	453	4.5	299
Westinghouse	WBE4500WC	425	4.5	292	453	4.5	299
Westinghouse	WBE4504BC	425	4.5	292	453	4.5	299
Westinghouse	WBE4504SC	425	4.5	292	453	4.5	299
Westinghouse	WBE5300BC	496	5	309	529	4.5	324
Westinghouse	WBE5300SC	496	5	309	529	4.5	324
Westinghouse	WBE5300WC	496	5	309	529	4.5	324
Westinghouse	WBE5304BC	496	5	309	529	4.5	324
Westinghouse	WBE5304SC	496	5	309	529	4.5	324
Westinghouse	WFB4204SC	388	3.5	309	425	3.5	380
Westinghouse	WFB4204WC	388	3.5	309	425	3.5	380
Westinghouse	WHE5204BC	491	4	363	524	3.5	419
Westinghouse	WHE5204SC	491	4	363	524	3.5	419
Westinghouse	WHE5264SC	491	4	363	524	3.5	419
Westinghouse	WHE6000SB	565	4	382	605	3.5	440
Westinghouse	WHE6060SB	565	4	382	605	3.5	440
Westinghouse	WHE6170BB	609	TBC	TBC	na	na	na
Westinghouse	WHE6170SB	609	TBC	TBC	na	na	na
Westinghouse	WHE6270SB	619	TBC	TBC	na	na	na
Westinghouse	WHE6874BA	609	3.5	501	681	3	560
Westinghouse	WHE6874SA	609	3.5	501	681	3	560
Westinghouse	WHE7074SA	619	3.5	501	702	3	575
Westinghouse	WQE6000BB	541	4	382	600	3.5	440
Westinghouse	WQE6000SB	541	4	382	600	3.5	440
Westinghouse	WQE6060BB	541	4	382	600	3.5	440
Westinghouse	WQE6060SB	541	4	382	600	3.5	440
Westinghouse	WQE6870BA	609	3.5	501	680	3	560
Westinghouse	WQE6870SA	609	3.5	501	680	3	560
Westinghouse	WRB5004SC	466	4	195	501	3.5	231
Westinghouse	WRB5004WC	466	4	195	501	3.5	231
Westinghouse	WTB2300WH	211	TBC	TBC	231	3.5	275
Westinghouse	WTB2500WH	225	TBC	TBC	245	3.5	282
Westinghouse	WTB2800AH	256	3	283	275	3.5	296
Westinghouse	WTB2800WH	256	3	283	275	3.5	296
Westinghouse	WTB3400AH	320	3	343	339	3.5	328
Westinghouse	WTB3400WH	320	3	343	339	3.5	328
Westinghouse	WTB3700AH	350	3	349	369	3.5	340
Westinghouse	WTB3700WH	350	3	349	369	3.5	340
Westinghouse	WTB4600SC	431	4	336	461	4	337
Westinghouse	WTB4600WC	431	4	336	461	4	337
Westinghouse	WTB4604SC	431	4	336	461	4	337
Westinghouse	WTB5400SC	503	4	353	536	4	366
Westinghouse	WTB5400WC	503	4	353	536	4	366
Westinghouse	WTB5404SC	503	4	353	536	4	366
